AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

Name: AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag Min
Brand: Aquatrin
Price: 12000 USD

China AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min wholesale

Brand Name : Aquatrin

Model Number : RCGF

Certification : ISO CE

Place of Origin : China

MOQ : 1unit

Price : USD12000-50000 1Set

Payment Terms : L/C, T/T

Supply Ability : 10units per month

Delivery Time : 45days

Packaging Details : wooden package

Material : stainless steel 304/316

Capacity : 1000-20000BHP

Function : Bottle Washing Filling Capping

Bottle type : PET Plastic Bottle

Keywords : small juice filling machine

Contact Now

Automatic 3 in 1 PET Bottle Washing Filling Capping Machine.

This washing filling capping machine is mainly used for Non-aerated carbon dioxide drink, such as mineral water, pure water and so on.The machine design is shorten the time for the drink material contact with outside, Increase the sanitation condition throughout economy benefit.

Final Products

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

Details Images

Automatic drinks filling machine line packaging specifications:				Material:SS304/316
Bottle material	Shape	Filling volume	Filling level(mm)	Neck type
Pet/Glass Bottle	Square/Round /Falt Bottle	100-2000ml	According request ±1mm	As request
Adjustable specifications of the bottle type	Bottle Size:Bottle diameter ≤120mm Bottle Height≤350mm
	If using square bottles, then bottle separating system will be added.
Filling temperature	5℃–80℃. Level control:Float ball and pneumatic butterfly valve.
Bottle labeling type		Packing system Min, Spec.		Palletizing system
Manual / Automatic Hot Melt Roll-Fed PVC Shrink Label Full Label/ Half Lable		Film shrinker Robert Packing Carton packing	23 24 34 35 44 45 4*6 6–30Bag/Min	Low position gantry palletizer Robot Palletizer High position
User Ambient Conditions		Temperature:2~40℃;Humidity:No dew
bottle feed-in	conveyor with screw for glass bottles		adopt air-conveyor for PET bottle.


Washing Part
Flip the bottle holder, the bottle holder clamps the bottleneck position, avoids the rubber clamp block on the traditional bottle holder to cause the possible pollution to the bottle mouth thread position. Bottle clamp is made of stainless steel AISI304, sanitary and durable.
 Filling Part

meet the requirements of hot filling and filling (the liquid level is controlled at about 15 mm, and the level level can be fine-tuned), so as to minimize the return flow of the material, thus providing hardware guarantee for ensuring the flavor of the product.

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

Capping Part

The capping system applies advanced French technology,when clamp the cap will screw immediately and magnetic torque type capping head

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

Cap loading machine

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

Pre-process system.

1 High-shear emulsifying tank + Plate heat exchanger 2 Mixing tank 3 UHT sterilizer + homogenizer machine + Buffer tank 4 Hot water system + Hot water tank 5 CIP cleaning system.

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

Bottle Inverter Chain

1/Use juice own high temperature to kill the bacterial inside cap. 2/Use juice own high temperature to improve sealing of bottle to extend warranty time. 3/Use SUS 304/316 stainless steel chain and high polymer material conveyor to keep high quality and increase service life.

Shower Cooling Machine.
1/Mainly for cooling and sterilization 2/The main parts of the machine are made of stainless steel, the top is designed to be openable for easy maintenance and observation 3/Nozzles are manufactured using U.S. technology and spray water evenly 4/Conveyor belt adopts Rexnor technology, flat surface with small wear 5/Smooth and reliable operation with low energy consumption

We suplly Free Factory Layout design

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

We suplly Free Bottle Shape design

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

Water treatment system

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

Labeling Machine

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

Laser date printer

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

PE film wrapping package machine

AISI304 20000BHP Vegetable Juice Bottling Machine 30 Bag / Min

FAQ

Q1:Are you a trading company or a manufactory?
 A1:We are a manufactory,can give u best service .

 Q2:What's your guarantee or the warranty of the quality if we buy your machines?
 A2:We offer you high quality machines with 2 years guarantee . we will give u spare part free in 2 years

 Q3:When can I get my machine after I paid?
 A3:We will deliver the machines on time as the date we agreed both side.

 Q4:How can I install my machine when it arrives?
 A4:We will send our engineer to your side as soon as you get all your machines ready , for testing and teaching your technicians how to run the machines.

 Q5:How about the spare parts?
 A5:After we deal down all the things , we will offer you a spare parts list for your reference.
