Automatic Small Apple Juice Unit Concentrate Production Line 3 In1 Pet Bottle Juice Filling Machine Line Price

Name: Automatic Small Apple Juice Unit Concentrate Production Line 3 In1 Pet Bottle Juice Filling Machine Line Price
Brand: Aquatrin
Price: 12000 USD

China Automatic Small Apple Juice Unit Concentrate Production Line 3 In1 Pet Bottle Juice Filling Machine Line Price wholesale

Brand Name : Aquatrin

Model Number : RCGF

Certification : CE ISO

Place of Origin : China

MOQ : 1unit

Price : USD12000-50000 1Set

Payment Terms : L/C, T/T

Supply Ability : 10units per month

Delivery Time : 45days

Packaging Details : wooden package

Color : Silver Gray Juice Filling Machine

Processing Types : Juice /MIlk Beverage

Function : 3 in 1 washing filling capping

Control : PLC + Touch Screen

Contact Now

RCGF series juice filling line is used to produce PET bottled juice within the volume from 200ml-2000ml.different models can satisfy various requirement of output from 1500B/H to 25000B/H.this machine incorporates ringsing,filling and capping into one kind of full-automatic equipment.The method of filling adopts hot filling .when the whole line compatibility is strong, can adapt to all kinds of bottle shape just change a few parts.it makes the operation more stable and reliable.the photoelectric sensor is used to detect operating confitions of each section,which makes the operation of this equipment highly automatic and convenient.

Automatic Small Apple Juice Unit Concentrate Production Line 3 In1 Pet Bottle Juice Filling Machine Line Price

Technical parameter

model	RCGF8-8-3	RCGF14-12-5	RCGF16-16-5	RCGF24-24-6	RCGF32-32-8	RCGF40-40-10
capacity(BPH)	1500	4000	5500	8000	10000	14000
washing heads	8	14	16	24	32	40
filling heads	8	12	16	24	32	40
capping heads	3	5	5	6	8	10
suitable bottle	PET bottle plastic bottle
diameter of bottle	55-100mm
height of bottle	150-300mm
suitable cap	plastic screw cap
weight(kg)	1500	2000	3000	5000	7000	7800
main motor power(kw)	1.2	1.5	2.2	2.2	3	5.5

Details Images

Washing heads

--Into bottle way is air conveyor direct connection with bottle dial. Air filter is positioned at every entrance of air fan, to
 prevent dust blown into bottles. - -All are made of stainless steel SUS 304 .they make the machine more durable.
 --304 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing.

Filling heads

- -Bottles are held on the neck in the conveyor and transported into filling machine by blowing power.- -Efficient spray nozzle rinse thoroughly and save water for flushing
 - -All 304 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean

Capping heads

- -Place and capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping - -All 304/316 stainless steel construction
 - -No bottle no capping - -Automatic stop when lack of bottle

Main Features

1)The equipment is fitted with advanced Mitshbish PLC to control the operation and cooperated by frequency converter of the main motor,It makes the operation more stable and reliable.
 2)Designed by the structure of suspension type getting stuck the bottleneck and conveying,filling valve lift technology to meet the requirement of heat filling within 95℃.
 3)There is constant temperature circulation system,self temperature control and liquid reflux .
 4)The machine parts of direct control with liquid like inlet valve used stainless steel SUS316 material.The main motor,reducer,bearings,sealing elements,electrical apparatus elements and pneumatic elements are all imported from well known manufacturers of the world.
 5)The photoelectric sensor is uesd to detect operating confitions of each section,which makes the operation of this equipment highly automatic and convenient.

Control System

S/N	Name	Brand	country
1	Main motor	ABB	Switzerland
2	Inverter	MITSUBISHI	Japan
3	PLC	OMRON	Japan
4	Touch screen	MITSUBISHI	Japan
5	Contactor	SCHNEIDER	France
6	Thermo- relay	SCHNEIDER	France
7	Air-break switch	SCHNEIDER	France
8	Proximity switch	TURCK	USA
9	Photoelectric switch	BANNER	USA
10	Air circuit system	SMC	Japan
11	Water pump	Southern	China

 Beverage pre-treatment system:
<1> The beverage processing system applies to beverage processing for hot filling line and CSD filling line.
 <2> product's scope hot water system, sugar dissolving system ( simple syrup system ), concentrate system, blending system (final syrup system), CIP system, extraction system, kind of storage tank / valves / pipe / fittings, UHT system (plate / tubular type), and carbo-cooler / mixer (manual / automatic)
 Tube UHT Sterilizer.
The tube(pipe) sterilize machine can take hot process on the liquid foods and beverage.
 Bottle Inverse Sterilizer Machine.
It is mainly used in sterilizing PET bottle mouth and inside surface of caps. in which haven't been disinfected by themal tea,fruit juice which having been filed in PET bottle.
