QGF-600 SUS316 5 Gallon Water Filling Machine 32KW Stainless Steel

Name: QGF600 SUS316 5 Gallon Water Filling Machine 32KW Stainless Steel
Brand: Aquatrin
Price: 2000 USD

China QGF-600 SUS316 5 Gallon Water Filling Machine 32KW Stainless Steel wholesale

Brand Name : Aquatrin

Model Number : QGF

Certification : ISO CE

Place of Origin : China

MOQ : 1unit

Price : USD2000-60000 1Set

Payment Terms : T/T

Supply Ability : 10units per month

Delivery Time : 45days

Packaging Details : wooden package

Filling range : 3-5 Gallon

Usage : Beverage Filling Packaging

Processing Types : Automatic Bottle Filling Sealing Machine

Material : Stainless Steel 304/316

Filling Accuracy : 99%

Product name : Promotional Top Quality 5 Gallon Bottling Water Filling Machine

Contact Now

Top Quality 5 Gallon Bottling Water Filling Machine

Full Automatic Barrel Production Line

The filling line special for 3-5 gallons barreled drinking water,with type of QGF-100,QGF-240,QGF-300,QGF-450,QGF-600,QGF-900,QGF-1200.It integrates bottle washing,filling and capping into one unit.In order to chineve the purpose of washing and sterilizing.The washing machine uses multi-washing liquid spray.This thimerosal can be used circularly.The capping machine can automatic.This line equips with water spraying device in order to ensure those caps sterile and clean.It also can automatic carry out barrel.Washing,sterilizing,filling capping,counting and products discharging.With complete fuction,modern design and high degree of automation.It is new kind of barreled water auto-producing line,which integrates mechanism,electricity and pneumatic technologies together.

Product Description

QGF-600 SUS316 5 Gallon Water Filling Machine 32KW Stainless Steel

5 Gallon Bottling Water Filling Machine.

This equipment is mainly composed of five gallons of automatic adjustment available outside the pull out cover machine, rotary brush barrels machines, automatic bucket machine, washing machine, normal pressure filling machine, cover, cover, cover, capping machine, intelligent steam heat shrinkable machine, on-line inspection, straight-line pail bagging machine, palletizing machine set, such as by conveying system connected into a continuous operation (flow) of the whole.

Product Details

Pull out cover machine.

Cap-pulling machine can be used alone, or online layout.Realize pipeline operations.The cap pulling head is mainly composed of cap pulling claw, cylinder and other components. The cap pulling head can be adjusted up and down, and the cap pulling claw can be fine-tuned. It does not hurt the bottle mouth and has strong applicability to different bottle mouths.The host machine is controlled by PLC. When the bottle runs to the cap-pulling position, the cap-pulling head drops, the cap-pulling claw grasps the edge of the bucket mouth cover, and the bucket is lifted and the lid is pulled out.

Washing Part.

When the power is connected, the PLC power starts to work, control the contactor to pull, so that the disinfectant pump starts to work, then output the signal PLC, so that the washing conveying motor and the filling conveying chain motor work, then the bucket washing mechanism makes the barrel body step by step into each process to start washing, the washing time can be programmed by the PLC controller.After rinsing, the drum falls to the pail rack.

Filling Part.

The filling head adopted by this equipment, when the bucket is sent to the filling position, it will automatically drop the
filling head under the control of PLC to fill the bucket.When filled, the filling valve returns and the bucket moves forward.After the cap manager is capped, he slips to the place where he hangs the cap and hangs the cap on the barrel.

Capping Part.

The gland is completed by the gland cylinder.When the bucket is close to the gland position, the detector detects and sends a signal, the gland cylinder moves instantaneously, and the gland is completed.With this form of capping, good effect, simple structure.

Barrel bagging machine.

The stopper cylinder falls and the conveyor chain sends a bottle under the lifting mechanism while the stopper cylinder rises to stop the rear cylinder from moving forward.Then the lifting mechanism goes down and lifts the bottle, and the staff sets the bag out of the bottle. The automatic time is flexible and adjustable.The lifting mechanism drops the bottle and the conveyor chain is sent out, at which point a procedure is completed.Repeat.

Product Paramenters

Model	QGF-100	QGF-240	QGF-300	QGF-450	QGF-600	QGF-900	QGF-1200
Filling heads	1	2	2	3	4	6	12
Volume (Gallon)	3&5	3&5	3&5	3&5	3&5	3&5	3&5
Barrel size(mm)	φ270*490	φ270*490	φ270*490	φ270*490	φ270*490	φ270*490	φ270*490
Capacity(b/h)	100	240	300	450	600	900	1200
Gas pressure(Mpa)	0.4-0.6	0.4-0.6	0.4-0.6	0.4-0.6	0.6	0.6	0.6
Gas consumption (m³/min)	0.37	0.37	0.6	0.8	1	1.5	1.8
Motor power(kw)	1.38	1.75	3.8	3.8	7.5	9.8	13.5
Weight(kg)	680	800	1500	2100	3000	3500	4500

Name	Brand	Area
PLC	Siemens	Germany
Inverter	Siemens	Germany
Contactor	Siemens	Germany
Touch screen	Siemens	Germany
Inverter	Siemens	Germany
Motor	ABB	Swiss
Pneumatic parts	FESTO	Germany
Electrical parts	Schneider	France

This machine is a fully automatic, high intelligent, stable and reliable blowing machine, with simple structure, and low energy consumption. It is very popular and well used in 3 - 5 Gallon Bucket Filling industry.
